Wheel loader 3080

Metric Imperial

		Z-kinematics (standard)
-	Standard tires	12.5/80 - 18 AS ET75 12.5/80 - 18 AS ET75
A	Total length	5,460 mm 215.0 in
B	Total length without bucket	4,649 mm 183.0 in
C	Bucket pivot point (to center of axle)	1,027 mm 40.4 in
D	Wheel base	2,005 mm 78.9 in
E	Rear overhang	1,531 mm 60.3 in
F	Height with cab lowered	2,458 mm 96.8 in
F	Height with cab raised	2,630 mm 103.5 in
H	Seat height	1,545 mm 60.8 in
J	Total working height	4,091 mm 161.1 in
K	Bucket pivot point (max. lift height)	3,351 mm 131.9 in
L	Load-over height	3,038 mm 119.6 in
M	Dumping height	2,541 mm 100.0 in
N	Reach (at M)	646 mm 25.4 in
O	Digging depth	105 mm 4.1 in
P	Total width	1,558 mm 61.3 in
Q	Track width	1,250 mm 49.2 in
S	Ground clearance	330 mm 13.0 in
T	Maximum radius	4,028 mm 158.6 in
U	Radius on the outer edge	3,584 mm 141.1 in
V	Inner radius	1,818 mm 71.6 in
W	Articulation angle	42 ° 42 °
X	Rollback angle at max. lift height	43 ° 43 °
Y	Dumping angle	39 ° 39 °
Z	Rollback angle on ground	49 ° 49 °

With the selection of different options, the technical data of the products can vary accordingly. Please note that equipment cannot be changed for editions.
Please note that the product range may vary depending on the country. Under certain circumstances, the contents / products shown here may not be available in your country. The illustrations, equipment, and data shown may also differ from the current product range in your country. Optional extras may be shown that are subject to an additional charge. Subject to changes.
