Wheel loader 9080

Metric Imperial

		Double P-kinematics (standard)
-	Standard tires	500 / 70 R24 Michelin XMCL ET 40 500 / 70 R24 Michelin XMCL ET 40
A	Total length	7,060 mm 278.0 in
B	Total length without bucket	6,270 mm 246.9 in
C	Bucket pivot point (to center of axle)	1,810 mm 71.3 in
D	Wheel base	2,660 mm 104.7 in
E	Rear overhang	1,520 mm 59.8 in
F	Height with cab	3,110 mm 122.4 in
H	Seat height	1,940 mm 76.4 in
J	Total working height	5,250 mm 206.7 in
K	Bucket pivot point (max. lift height)	4,260 mm 167.7 in
L	Load-over height	3,980 mm 156.7 in
M	Dumping height	3,300 mm 129.9 in
N	Reach (at M)	1,140 mm 44.9 in
O	Digging depth	136 mm 5.4 in
P	Total width	2,390 mm 94.1 in
Q	Track width	1,820 mm 71.7 in
S	Ground clearance	502 mm 19.8 in
T	Maximum radius	5,630 mm 221.7 in
U	Radius on the outer edge	4,900 mm 192.9 in
V	Inner radius	2,450 mm 96.5 in
W	Articulation angle	40 ° 40 °
X	Rollback angle at max. lift height	45 ° 45 °
Y	Dumping angle	45 ° 45 °
Z	Rollback angle on ground	48 ° 48 °

With the selection of different options, the technical data of the products can vary accordingly. Please note that equipment cannot be changed for editions.
Please note that the product range may vary depending on the country. Under certain circumstances, the contents / products shown here may not be available in your country. The illustrations, equipment, and data shown may also differ from the current product range in your country. Optional extras may be shown that are subject to an additional charge. Subject to changes.
